Some Space Stations in Fiction and Reality

6 minute read (857 words)

An earlier post in my teaching resources for a final year undergraduate project had a pretty helpful AI-generatedthanks to Claude table. This is a quick post about Wernher von Braun’s 1950’s conceptual rotating wheel station with some basic comparisons to the ISS (1998-present) and 1968’s Space Station V from 2001: A Space OdysseyWatch this as homework! .

Von Braun’s Rotating Wheel Space Station

Wernher von Braun’s video envisioned a rotating wheel space station with 9 sections for:

  1. Headquarters and Communications
  2. Earth Weather Observation/Prediction
  3. Military Reconnaissance using Optical and Radar Telescopes
  4. Emergency Hospital Section
  5. Astronomy
  6. Calculation Machines and a lower/outer deck with maintenance facilities
  7. A/C equipment
  8. Living quarters
  9. Botanical and Zoological Laboratory The video shows two decks per section, which I assume is 6 $m$ in heigh (i.e. the habitable portion between the outer rim and inner rim). Wikipedia says the concept had 3 decks but as I haven’t looked that up, I will stick to two 6 $m$ decks for now.

The system is powered by an atomic reactor attached on one side of its central hub; its heat will drive a turbo generator to power the station. Radio and radar antennas sit atop the reactor. The other side of the hub has an airlock for astronauts to access/exit the space station via smaller spacecraft. Like a bicycle wheel, the system had thin spokes are condensers for the turbo generator and air-conditioning plant. Three larger tubes are elevator shafts that connect the hub to the main habitable sections of the wheel station. The station would:

  • host 50 astronauts though Wikipedia states 80 people.
  • rotate at roughly 3 rpm to produce artificial gravity on the rim; and
  • be a torus of 250 $ft$ (76 $m$) diameter. The distance from the center of the tube to the center of the torus is $R = 70/2 = 35 \, m$ and the minor radius of the tube is $r = 6/2 = 3 \, m$. The volume of this torus is then the station’s total pressurized volume, which is given by \((V_{tot})_{vB} = 2 {\pi^2} R {r^2}\).

So, we can estimate that the von Braun space station has a:

  • Total Pressurized Volume: = 6217.85 $m^3$
  • Habitable Volume = 3730.71 $m^3$

Here, I assumed that 60% of the pressurized volume is habitable. This is a considerably more optimistic percentage compared to the 42% of ISS.

How did von Braun imagine its realisation?


Assembly of the Modular Rotating Wheel Space Station.
Condenser pipes being unwound for installation.

The short-version is that he assumed predominantly modular robotic assembly and a minor reliance on inflatables for the airlock. First, the hub is inflated using compressed air from built-in tanks. Protection from meteors is ensured by putting thin metal plates; this is unnecessary today as we have developed high-strength textiles that are used on inflatable space stations. A second launch brings with it an airlock, which is again attached by robots; this allows the pressurized hub to be used as a temporary quarters as the station assembly continues with astronaut-robot teams. Pre-fabricated and tested on the ground after which it is dismantled and assembled robotically in-orbit. A number successive launches (he says) ensure the “parts of the station are assembled in the correct order”. Nylon tethers prevent parts from drifting away. The reactor appears to be the next big piece that is installed so I assume this is the third launch. This is followed by the elevator shafts and the rim sections being brought together. We can assume a single launch for each module: $3$ elevator tubes and 9 rim modules (assuming one per section). Assuming condenser pipes are installed from one launch (but the structure itself needs to be unwound robotically, which seems unreasonable/unreal at the moment as a robotic task.

Lastly, the installation of instruments/equipment (a simple catch-all term for imaging antennas and the lab facilities compute for astronomical/Earth Observation data analysis, I think) and two small rocket motors on the rim. These rocket motors “blast for a few seconds” to revolve the station at about $3 \, RPM$.

Comparing to ISS and Space Station V (2001: A Space Odyssey)

Table 1: Comparing the ISS to fictional ideas.

  ISS von Braun Space Station V
crew size (# of astronauts) 7-13 50-80 2
diameter of the station (m) n/a 75 300
total volume $m^3$ 916 6217.85 26647.93
habitable % 42.35% 60% (assumed) ?
Max. volume per crew $(\frac{m^3}{person})$ 64.66 52.67 assuming 50 crew 13223.46
Rotational speed for artificial gravity (RPM) - 3 2.44
Gravity on-board ($m/s^2$) - 1.655 9.81

Some gaps in von Braun design

  1. Assumes a launch every 24 hours- not close to it then and not really close to that kind of cadence today. What could we do today?
  2. Doesn’t really say how many launches are needed to realize assembly in the video. This can probably be found elsewhere but my estimate from watching the video is 15-18 launches.
  3. The process involves a number of assembly robots but we barely have one of these today. And whatever is there not autonomous.
  4. Materials used in assembly are unknown.
  5. Telescope sizes for reconnaisance and astronomy are unknown.
  6. Power requirements are unknown.
  7. What else?
